Temperature range: -150~650

Component type: Ptl00

Accuracy: + 0.03 DEG C (-150~320 C)

* probe length: 250mm, 350mm, 500mm

Probe diameter: A type 4mm, type 6.35mm B

.90 degree right angle probe 207mm

.4 gold plated LEMO connector

Fast response, low drift, high stability

Stainless steel tube

Traceable calibration certificate

Applicable to DTI-1000, DTI050, ATC-B series, ASC301, AMC901

option

STS050 all

STS050 -50 to 400 DEG C reference temperature sensor

A probe diameter 4mm (0.16 in)

B probe diameter 6.35mm (0.25 in)

250 straight probe, 250mm (9.8 in)

350 straight probe, 350mm (13.8 in)

500 straight probe, 500mm (19.7 in)

90190 degree probe, 207mm (8.1 in) - only for type B

D 1 m cable with Redel connector for DTI050

F traceable certificate -45 to 650 DEG C

H ISO17025 accreditation certificate -45 to 650 DEG C

STS100 all

STS100 -150 to 650 DEG C reference temperature sensor

A probe diameter 4mm (0.16 in)

B probe diameter 6.35mm (0.25 in)

250 straight probe, 250mm (9.8 in)

350 straight probe, 350mm (13.8 in)

500 straight probe, 500mm (19.7 in)

90190 degree probe, 207mm (8.1 in) - only for type B

A 0.5 m (1.6 ft) cable with LEMO / LEMO joint

B 2 m (6.6 ft) cable with LEMO / LEMO joint

C 2 m (6.6 ft) cable with LEMO / Banana joint

D LEMO / Redel junction with 2 m (6.6 ft) cable, suitable for DTI050

HL ISO17025 accreditation certificate -90 to 125 DEG C

F traceable certificate -45 to 650 DEG C

FL traceable certificate -90 to 125 DEG C

G NIST traceable certificate -45 to 650 DEG C

I certificate or coefficient

STS102 all

STS102 -50 to 155 DEG C reference temperature sensor

A probe diameter 4mm (0.16 in)

030 short sensor at 30mm (1.18 in)

The integration of Teflon S with LEMO connectors 1 m (3.3 ft) cable

D LEMO / Redel junction with 1 m (3.3 ft) cable, suitable for DTI050

E LEMO / Redel junction with 1 m (3.3 ft) cable, suitable for RTC

H ISO17025 accreditation certificate -45 to 155 DEG C

F traceable certificate -45 to 155 DEG C

G NIST traceable certificate -45 to 155 DEG C

I certificate or coefficient

STS103 all

B probe diameter 3mm (0.12 in)

A 0.5 m (1.6 ft) cable with LEMO / LEMO joint

B 2 m (6.6 ft) cable with LEMO / LEMO joint

C 2 m (6.6 ft) cable with LEMO / Banana joint

H ISO17025 accreditation certificate -45 to 400 DEG C

F traceable certificate -45 to 400 DEG C

G NIST traceable certificate -45 to 400 DEG C

I certificate or coefficient

STS150 all

A probe diameter 4mm (0.16 in)

91290 degree probe, suitable for PTC-125 series, -90 to 125 DEG C

91590 degree probe, suitable for PTC-155 series, -25 to 155 DEG C

93590 degree probe, suitable for PTC-350 series, 0 to 350 DEG C

96690 degree probe, suitable for PTC-660 series, 0 to 660 DEG C

E LEMO / Redel junction with 0.5 m (1.6 ft) cable, suitable for RTC/PTC

H ISO17025 accreditation certificate

F traceable certificate

I certificate or coefficient

STS200 all

A probe diameter 4mm (0.16 in)

B probe diameter 6.35mm (0.25 in)

91590 degree probe, suitable for RTC-156, 157 series, -65 to 160 DEG C

91790 degree probe, suitable for RTC-159 series, -100 to 160 DEG C

92590 degree probe, suitable for RTC-250 series, 0 to 250 DEG C

97090 degree probe, suitable for RTC-700 series, 0 to 700 DEG C

A 0.5 m (1.6 ft) cable with LEMO / LEMO joint

B 2 m (6.6 ft) cable with LEMO / LEMO joint

C 2 m (6.6 ft) cable with LEMO / Banana joint

D LEMO / Redel junction with 2 m (6.6 ft) cable, suitable for DTI050

E LEMO / Redel junction with 0.5 m (1.6 ft) cable, suitable for RTC/PTC

H ISO17025 accreditation certificate

F traceable Certificate (including)

I certificate or coefficient

parts

60-F100 insulation pipe, 100mm x is 25mm

60-F101 insulation pipe, 150mm x is 25mm

65-F102 insulation pipe, 200mm x is 25mm

65-F103 insulation pipe, 250mm x is 25mm

65-F104 insulation pipe, 300mm x is 25mm

65-F105 insulation pipe, 350mm x is 25mm

65-F106 insulation pipe, 400mm x is 25mm

65-F107 insulation pipe, 450mm x is 25mm

105173 heat shield Kit (10 pieces)

125068 sensor strut assembly (2 handles, 2 clamps)

125066 sensor handle additional fixture

125067 additional sensor handle

127787 m cable with Redel male connector / Redel female connector (STS-050) 2

122801 m cable with LEMO / LEMO joints of 0.5

65-PT100-LL-CABLE 2 m cable with LEMO / LEMO connector

65-PT100-LB-CABLE 2 m (6.6 ft) cable with LEMO / Banana connector

125522 LEMO / Redel connector with a length of 2 m cable

123859 for the calibration of health sensors complete suite of applications, including: STS102A030SH, re calibration sleeve, manual, 5 tape cable trough undrilling casing, portable box
