科普文章之电能质量分析仪产品相关标准介绍
标准协会：
1、IEC (international electrotechnical commission) 国际电工委员会
2、EN (European norm) 欧洲标准
3、IEEE SA (the institute of electrical and electronics engineers standards association) 电气和电子工程师协会 标准协会
4、UL (Underwriteries Laboratories) 美国安全检定实验室
5、DIN (Deutsches Institut für Normung) 德意志标准化协会
标准名称：
1、EN50160 voltage characteristics of electricity supplied by public distribution systems
公共配电系统供电的电压特性
2、IEC61000-4-30 EMC part 4-30 testing and measurement techniques- power quality measurement methods
测试和测量技术-电能质量测量方法
3、IEC62586-1 power quality measurement in power supply systems-part 1 power quality instruments (PQI)
电源系统中的电能质量测量-第一部分 电能质量仪器
4、IEC62586-2 power quality measurement in power supply systems-part 2 functional tests and uncertainty requirements
电源系统中的电能质量测量-第二部分 功能测试和不确定度要求
5、IEC61000-4-7 EMC part 4-7 testing and measurement techniques- general guide on harmonics and interharmonics measurements and instrumentation ,for power supply systems and equipment connected thereto
EMC 第4-7部分 测试和测量技术-谐波和间谐波和仪器仪表的一般指南，用于电源系统和与之相连的设备
6、IEC61000-4-15 EMC part 4-15 testing and measurement techniques- flickermeter-functional and design specifications
EMC 第4-15部分 测试和测量技术-闪烁计-功能和设计规范
7、IEC61000-2-2 EMC environment-compatibility levels for low-frequency conducted disturbances and signalling in public low-voltage power supply systems
EMC 环境-公共低压供电系统中低频传导干扰和信号的兼容性水平
8、IEC61000-2-4 EMC part 2-4 environment-compatibility levels in industrial plants for low-frequency conducted disturbances (three classes)
EMC 第2-4部分 环境-工业厂房中低频传导干扰的兼容性水平(支持三种等级)
9、IEC61000-2-12 EMC part 2-12 environment-compatibility levels for low-frequency conducted disturbances and signalling in public medium-voltage power supply systems
EMC 第2-12部分 环境-公共中压供电系统中低频传导干扰和信号的兼容性水平
10、IEC61000-6-4 EMC part 6-4: emission standard for industrial environments
EMC 第6-4 部分：工业环境排放标准
11、IEC61000-6-5 EMC part 6-5: immunity for equipment used in power station and substation environment
EMC 第6-5 部分：对电站和变电站环境中使用的设备的抗扰度
12、IEC61557-12 electrical safety in low voltage distribution systems up to 1000V AC and 1500V DC-equipment for testing,measuring or monitoring of protective measures-part 12: power metering and monitoring devices (PMD)
最高到1000V AC和1500V DC的低压配电系统的电气安全-测试，测量或监测保护措施的设备-第12部分：功率计量和监控设备
13、IEC TR 63191 demand side power quality management
需求侧电能质量管理
14、IEC62053-22 electricity metering equipment-particular requirements-part 22: static meters for ac active energy(classes 0,1S,0,2S and 0,5S)
电能计量设备-特殊要求-第22部分：交流有功电能静态仪表（0,1S,0,2S 和 0,5S等级）
15、IEC62053-24 electricity metering equipment-particular requirements-part 24: static meters for fundamental component reactive energy (classes 0,5S,1 S ,1, 2 and 3)
电能计量设备-特殊要求-第24部分：基波分量无功电能静态仪表(0,5S,1 S ,1, 2 and 3等级)
16、IEC62053-31 pulse output devices for electromechanical and electronic meters(S0 output)
机电和电子表计的脉冲输出装置（S0 输出）
17、EN60297 mechanical structures for electrical and electronic equipment-dimensions of mechanical structures of the 482,6mm(19inch)series
电气和电子设备的机械结构- 482,6mm 19寸 系列机械结构尺寸
18、IEEE519 harmonic control in electric power systems
电气系统中的谐波控制
19、IEEE1159 recommended practice for monitoring electric power quality
监测电能质量的推荐方法
20、IEEE1459 definitions for the measurement of electric power quantities under sinusoidal,nonsinusoidal,balanced,or unbalanced conditions
正弦，非正弦，平衡或不平衡条件下电气量测量的标准定义
21、IEEE1453 standard for measurement and limits of voltage fluctuations and associated light flicker on ac power systems
交流电源系统上电压波动和相关光闪烁的测量和限值标准
22、IEC60051 direct acting indicating analogue electrical measuring instruments and their accessories
直接作用指示模拟电测量仪器及其附件
23、EN50600-2-2 information technology-data center facilities and infrastructures-part 2-2 power distribution
信息技术-数据中心设施和基础设施-第2-2部分 配电
24、ENEL GSTQ001 fixed installed indoor power quality instrument
意大利国家电力公司 固定安装的室内电能质量仪表
25、ENEL GSTQ002 extended power quality data interchange formats
意大利国家电力公司 扩展电能质量数据交换格式
26、IEC60068-2-1/2/3/6/27 environmental testing-cold/dry heat/damp test/vibration/shock
环境测试-冷/干热/潮湿测试/振动/冲击
27、IEC60529 degrees of protection provided by enclosures (IP code)
外壳提供的保护程度 （IP 等级）
28、IEC61131-2 industrial-process measurement and control–programmable controllers-part 2: equipment requirements and tests (digital inputs/outputs 12/24v DC)
工业-过程测量和控制-可编程控制器-第2部分：设备要求和测试 (数字 输入/输出 12/24v DC)
29、UL94 standard for safety of flammability of plastic materials for parts in devices and appliances testing
设备和电器测试中零件的塑料材料可燃性安全标准
30、IEC60038 IEC standard voltages
IEC 标准电压定义和分类
31、2011/65/EU(RoHS) EU directive on the restriction of the use of certain hazardous substances
关于限制使用某些有害物质的指令
32、IEC61850 communication networks and systems for power utility automation
用于电力设施自动化的通信网络和系统
33、IEC60688 electrical measuring transducers for converting AC and DC electrical quantities to analogue or digital signals
用于将交流和直流电量转换为模拟或数字信号的电测量传感器
